| 低温冷冻(R22，EVI) | ||||||||||
| 型号 | 匹数 | 电源 |
排量 (cc/rev) |
制冷量 (W) |
输入功率 (W) |
制冷 COP |
运行电流 (A) |
**运行电流 (A) | 润滑油 | 冷媒 |
| YSF60A1G-V100 | 7 | 380-420V/3~/50Hz | 115.5 | 6000 | 4170 | 1.44 | 9.2 | 17.6 | 3GS | R22 |
| YSF65A1G-V100 | 8 | 380-420V/3~/50Hz | 123.0 | 6400 | 4450 | 1.44 | 9.6 | 19.0 | 3GS | R22 |
| YSF75A1G-V100 | 9 | 380-420V/3~/50Hz | 145.4 | 7400 | 5070 | 1.46 | 10.4 | 22.0 | 3GS | R22 |
| YSF85A1G-V100 | 10 | 380-420V/3~/50Hz | 167.2 | 8480 | 5800 | 1.46 | 11.2 | 25.0 | 3GS | R22 |
| YSF90A1G-V100 | 12 | 380-420V/3~/50Hz | 189.1 | 9500 | 6420 | 1.48 | 12.1 | 28.0 | 3GS | R22 |
| YSF100A1G-V100 | 13 | 380-420V/3~/50Hz | 197.1 | 10000 | 6760 | 1.48 | 12.6 | 24.7 | 3GS | R22 |
| YSF125A1G-V100 | 15 | 380-420V/3~/50Hz | 243.7 | 12200 | 8714 | 1.40 | 16.7 | 30.4 | 3GS | R22 |
| 低温冷冻(R404A，EVI) | ||||||||||
| 型号 | 匹数 | 电源 |
排量 (cc/rev) |
制冷量 (W) |
输入功率 (W) |
制冷 COP |
运行电流 (A) |
**运行电流 (A) | 润滑油 | 冷媒 |
| YSF60E1G-V100 | 7 | 380-420V/3~/50Hz | 115.5 | 6910 | 4369 | 1.58 | 9.5 | 17.9 | POE | R404A |
| YSF65E1G-V100 | 8 | 380-420V/3~/50Hz | 123.0 | 7360 | 4660 | 1.58 | 10.0 | 19.1 | POE | R404A |
| YSF75E1G-V100 | 9 | 380-420V/3~/50Hz | 145.4 | 8704 | 5440 | 1.60 | 10.8 | 22.3 | POE | R404A |
| YSF85E1G-V100 | 10 | 380-420V/3~/50Hz | 167.2 | 10010 | 6256 | 1.60 | 11.9 | 25.7 | POE | R404A |
| YSF90E1G-V100 | 12 | 380-420V/3~/50Hz | 189.1 | 11320 | 6988 | 1.62 | 12.9 | 28.8 | POE | R404A |
| YSF100E1G-V100 | 13 | 380-420V/3~/50Hz | 197.1 | 11800 | 7284 | 1.62 | 13.3 | 27.0 | POE | R404A |
| YSF125E1G-V100 | 15 | 380-420V/3~/50Hz | 243.7 | 13500 | 9507 | 1.42 | 18.0 | 33.4 | POE | R404A |
